Industrial Furnaces Ceramic Fiber Blanket Boiler Insulation Blanket

Brand Name : SUNWOOL

Model Number : Ceramic Fiber Blanket

Certification : ISO CE

Place of Origin : China

MOQ : 10roll

Price : 5.5-9.9usd/roll

Payment Terms : L/C,D/P,T/T,Western Union

Supply Ability : 10000rolls/month

Delivery Time : 10days

Packaging Details : woven bag/carton

Refractoriness : 1050-1800C

Size : Customizable

Package : bag or carton box or pallet

Shape : Customizable

Color : White

Type : blanket board module paper textile

Contact Now

Ceramic Fiber Blanket – Flexible, High-Temperature Insulation for Demanding Industrial Applications
Product Overview:

Our Ceramic Fiber Blanket is composed of long, flexible, interwoven fibers manufactured by the “blown” and “spun” process. It yields a strong, lightweight, and durable blanket designed for continuous service in a temperature range from 1100°C to 1430°C, depending on the grade. It combines the heat resistance of a hard refractory with a thermal insulation value five times better, making it an ideal solution for energy saving and thermal management.

Technical Index
Description STD Blanket High Pure Blanket High zirconium Blanket
AL2O3(%) ≥44 ≥45 ≥34
AL2O3+SiO2 (%) ≥96 ≥99 ≥84
Fe2O3+TiO2(%) ≤1.0 ≤0.5 ≤0.5
ZrO2 (%) - - ≥15
K2O+Na2O(%) ≤1.0 ≤0.2 ≤0.2
Density (kg/m3) 64 96 128 96 128 128 160
Classification Temperature
(℃)
1260 1260 1430
Fiber Diameter(um) 3.5 3.5 3.5
Shot Content(%) ≤15 ≤15 ≤15
Shrinkage after Heating (%) 1000C *24h≤2.5 1100C *24h≤2.5 1350C *24h≤3.5
Thermal Conductivity(W/m·k)
400℃ 0.090 0.095 0.124 0.114 0.101 0.138 0.122 0.118
500℃ 0.119 0.123 0.145 0.135 0.120 0.179 0.153 0.149
600℃ 0.152 0.158 0.202 0.191 0.175 0.233 0.184 0.172
Tensile Strength(Mpa) 0.040 0.05 0.05 0.060 0.075 0.050 0.060 0.075
Key Features:
  • Low Thermal Conductivity: Excellent insulation properties reduce heat loss.
  • Very Low Heat Storage: Enables rapid heating and cooling cycles.
  • High Tensile Strength: Durable and resistant to tearing during handling and installation.
  • Excellent Thermal Shock Resistance: Performs reliably under rapid temperature changes.
  • No Binder, Safe: Contains no binders, producing no fumes or furnace atmosphere contamination. It is asbestos-free.
  • Quick Installation & Repair: Requires no curing or dry-out time; can be fired to operating temperature immediately. Damaged linings can be cooled and repaired quickly.
Applications:
  • Ceramic Industry: Kiln car insulation and seals, continuous and batch kilns.
  • Steel Industry: Heat treating/annealing furnaces, furnace door linings, soaking pit covers, ladle covers, hot face repairs.
  • Refining & Petrochemical: Reformer and pyrolysis lining, tube seals/gaskets, high-temperature pipe/duct insulation.
  • General: Back-up insulation, expansion joints, and areas requiring sound absorption.

Industrial Furnaces Ceramic Fiber Blanket Boiler Insulation Blanket

Industrial Furnaces Ceramic Fiber Blanket Boiler Insulation Blanket

Industrial Furnaces Ceramic Fiber Blanket Boiler Insulation Blanket

Industrial Furnaces Ceramic Fiber Blanket Boiler Insulation Blanket
