Rock Mineral Wool High Quality Thermal Insulation Fireproof Soundproof With Aluminum Foil For Wall Roof Ceiling Building Construction
External thermal insulation rock wool board is specially designed for external thermal insulation composite system.It has the quality of high tensile strength, good dimensional stability, water repellent, low water absorption etc. We have three different products to meet customer's needs i.e. LR140, LR160, LR180.
Rock wool products is base on superior melted basalt as the main raw material, through centrifuge system of four-roller cotton process which pulls melted basaltic rockwool into a 4 ~ 7μm non continuous fibers followed by adding a certain amount of binder,dust laying oil, water repellent before settlement folding, curing, cutting and other processes, and then made into the productsof different density depending on purpose of usage like blanket or board or pipe etc shapes .meanwhile it can be non-faced or faced with wire mesh. This material using in construction.Petroleum, electric power, chemical industry equipment’s thermal insulation and Building partition wall, curtain wall, roof and building envelope thermal insulation
|
Product performance
|
Unit
|
LDS 60-200
|
Standard
|
|
Apparent Density
|
kg/m3
|
140
|
160
|
180
|
GB/T5480
|
|
Compression strength(10%defomation)
|
kPa
|
≥40
|
≥50
|
≥60
|
GB/T13480
|
|
Tensile strength (perpendicular to surface)
|
kPa
|
≥7.5
|
≥10
|
≥15
|
JG149-2003
|
|
Thermal conductivity(25℃)
|
w/(m•K)
|
≤0.040
|
≤0.040
|
≤0.040
|
GB/T10295
|
|
Fire resistant
|
--
|
Non-combustible grade A
|
GB/T8624
|
|
Water repellence
|
%
|
≥98
|
≥98
|
≥98
|
GB/T10299
|
|
Acid index
|
--
|
≥1.8
|
≥1.8
|
≥1.8
|
GB/T5480
|
|
Moisture absorption
|
%
|
≤1.0
|
≤1.0
|
≤1.0
|
GB/T5480
|
|
water Absorption(partial immersion 24h)
|
kg/m2
|
≤0.5
|
≤0.5
|
≤0.5
|
GB/T25975-2010
|
|
water Absorption(partial immersion 28d)
|
kg/m2
|
≤2.0
|
≤2.0
|
≤2.0
|
GB/T25975-2010
|
|
Noise Reduction Coefficient(NRC)
|
---
|
≥0.6
|
≥0.6
|
≥0.6
|
GB/T18696
|
|
Dimension Stability
|
%
|
≤1.0
|
≤1.0
|
≤1.0
|
GB/T8811
|
|
Thickness Tolerance
|
mm
|
±3
|
±3
|
±3
|
GB/T5480
|
|
Squareness
|
mm/m
|
≤5
|
≤5
|
≤5
|
GB/T5480
|
|
Flatness
|
mm
|
≤6
|
≤6
|
≤6
|
GB/T25975-2010
|
|
Melting Point
|
℃
|
＞1000
|
|
Application:
1.Other places that has high requirement for fire-proof, thermal insulation, water-proof etc.
2,Suitable for dry hanging stone curtain wall, aluminum-plastic composite plate curtain wall, aluminum panel curtain wall insulation system etc.
3.This product is specially designed for external thermal insulation composite system.
4.Used as fire barrier for external thermal insulation composite system of non-class A fire classification insulation.
Packing and storage:
For the convenience of working and storage our product is packed with polyethylene heat shrinkable film.
And should be stored in dry and ventilated room or in an open area covered with water-proof cover.
